CICERO spinning disk

A flexible, compact but full-fledged spinning-disk confocal solution, CICERO makes high-end fluorescence imaging accessible to every laboratory enabling a variety of applications.

Home / Products / Crestoptics / CICERO

Gallery

Overview

CICERO is a complete widefield and spinning disk solution, it can be integrated into any imaging setup transforming it into a user-friendly and reliable confocal system. Life sciences, metrology, and material sciences are among the disciplines relying increasingly on high-resolution 3D imaging.

CICERO spinning disk solution delivers fast image acquisition speed (15K rpm) and sensitivity, easily enabling live cell imaging and large-scale 3D object imaging. Due to its large field of view (up to 22mm FOV), CICERO offers a minimal scanning process and can capture large samples in a single frame.

CICERO is a reliable and flexible solution compatible with both LED and Laser as illumination sources. Moreover, the wide spectral range enables a large variety of applications. For this, CICERO allows to address both entry-level and challenging applications.

Specifications

FOV	Up to 22mm
Bypass Mode	Yes (manual)
Light Source	LED (3mm LLG) and multimode Laser (SMA fiber)
Spectral range	Excitation: 390-750 nm ; Emission: 430-850 nm (*)
Camera	C-mount camera
Resolution	Lateral Resolution (FWHM): ~230 nm (100X NA 1.45) Axial Resolution (FWHM): ~600 nm (100X NA 1.45)
Software	NIS Elements / LAS X 3.10.0 Build 28982 / μManager / VisiView® / Volocity / SDK available for integration
Configurations	Upright and Inverted Microscope
Weight	7.65Kg \| 16.8 lbs
Dimensions	166.20 (w) x 234 (l) x 228.60 (h) mm 6.54 (w) x 9.21 (l) x 9 (h) inches
